Factory Tour

JingTai LCD Technology – Manufacturing Capabilities & Production Excellence

Global Manufacturing Capacity & Infrastructure

Jingtai LCD operates state-of-the-art production facilities capable of delivering 2.4 million LCM modules monthly. Our manufacturing environment includes Class 10K/100K cleanrooms for critical assembly processes, ensuring the highest level of product quality and reliability. With 80% automation across production lines and integrated real-time quality monitoring, we maintain exceptional consistency and precision for international clients.

Specialized Production Lines for Diverse Applications

A. Automated LCM Assembly Lines

1. 6 fully automated assembly lines

2. Capacity: 400K units/month per line

3. Key processes:

3.1 High-precision COG (Chip-on-Glass) bonding

3.2 FOG (Flex-on-Glass) attachment

3.3 Integrated backlight assembly

3.4 Component placement tolerance: ±0.1mm

B. Optical Bonding & Lamination Lines

1. 4 dedicated optical bonding lines

2. Advanced bonding capabilities:

2.1 OCA (Optically Clear Adhesive) lamination

2.2 LOCA (Liquid Optically Clear Adhesive) dispensing

2.3 Support for curved displays (R≥3D)

C. Special Processes & Testing

1. Touch integration: On-cell and GFF solutions

2. Environmental testing chambers:

2.1 72-hour continuous operation testing

2.2 Thermal cycling: -30°C to +85°C

3. Mechanical lifespan testing: 50,000+ cycles

Quality Assurance & Compliance

1. Automated Optical Inspection (AOI): 100% panel inspection using 5MP cameras

2. Signal Testing: MIPI/RGB/LVDS protocol validation

3. Reliability Testing:

3.1 500h high-temperature/humidity (85°C/85%RH)

3.2 50,000x mechanical endurance testing

4. Certifications: ISO 9001, IATF 16949, ISO 14001, ESD S20.20

Flexible Manufacturing Options

1. Small Batch: MOQ 500pcs (15-day lead time)

2. Mass Production: 1M+ units with JIT delivery options

3. Dedicated Lines: Automotive-grade (IATF 16949) production

Why Choose JingTai LCD?

Global Experience: 20+ years serving international markets

High Efficiency: Dual-shift production (20h/day operation)

Excellent Yield: 99.2% for standard LCM products

Supply Chain Flexibility: Compatible with major panel suppliers (BOE/AUO/Tianma/IVO)

Quality Focus: Rigorous testing and compliance with international standards

Let's Discuss Your Project Requirements

We offer customized production solutions for:

Industrial and automotive displays

Medical and military-grade applications

Consumer electronics and IoT devices

Contact us today for a detailed production plan and competitive quotation.

JingTai LCD Technology – Your Trusted OEM/ODM Display Solutions Partner

Comprehensive End-to-End Display Solutions

As a professional OEM/ODM partner with over a decade of industry experience, JingTai LCD provides complete display solutions from initial concept to mass production. We specialize in developing custom LCD modules that meet your exact specifications, supported by our advanced manufacturing capabilities and engineering expertise. Our team works closely with clients across diverse industries to deliver innovative, reliable, and cost-effective display solutions.

1. Core Technical Capabilities

Custom LCM Development: Full customization of sizes ranging from compact 0.96-inch to large 17-inch displays, with support for various resolutions and interfaces including MIPI, LVDS, eDP, SPI, and I²C

Advanced Display Technologies: Implementation of IPS/LTPS/In-Cell panel technologies, OTP calibration for precise color performance, and innovative design features including waterdrop notches and blind-hole cutouts

Vertical Integration: Strategic partnerships with leading panel suppliers (BOE, AUO, Tianma) ensuring optimal component sourcing and supply chain stability

Engineering Expertise: 30-member R&D team with extensive experience in display technologies and system integration

2. OEM Services: Modification and Branding Solutions

Standard Product Customization: Modification of existing LCM designs to include client branding, customized firmware, and specific interface requirements

Cost-Effective Manufacturing: Leverage our mature production lines with 2.4 million units monthly capacity for competitive pricing and reliable delivery

Rapid Turnaround: Efficient production processes ensuring quick time-to-market for modified designs

Quality Assurance: Comprehensive testing and validation to ensure modified products meet original performance standards

3. ODM Services: Complete Custom Display Development

Full Custom Design: Collaborative development of displays specifically engineered for unique applications in automotive, medical, industrial, and consumer electronics

End-to-End Support: Complete service covering industrial design, optical engineering, prototyping, testing, and mass production

Industry-Specific Certifications: Compliance with IATF 16949 for automotive applications, ISO 13485 for medical devices, and other relevant industry standards

Prototype Development: 15-day rapid prototyping cycle for urgent project requirements

4. Industry-Specific Solutions

Automotive Displays: Sunlight-readable, wide-temperature range displays with automotive-grade reliability

Medical Equipment: High-brightness, high-contrast displays meeting medical safety and compliance requirements

Industrial Applications: Ruggedized displays with wide viewing angles and extended temperature ranges

Consumer Electronics: Innovative designs featuring slim bezels, high resolution, and advanced touch technologies

IoT Devices: Low-power consumption displays with optimized cost-performance ratios

5. Why Choose JingTai LCD as Your Display Partner?

Proven Track Record: Successful partnerships with leading brands including Transsion, ZTE

Technical Expertise: 10+ years of specialized experience in display technologies and manufacturing

Global Compliance: Products meet RoHS, REACH, CE, and other international safety and environmental standards

Agile Response: Dedicated project management ensuring quick response times and efficient communication

Quality Commitment: Rigorous quality control processes throughout design, prototyping, and production phases

6. Our Client Success Stories

Developed custom automotive displays for leading electric vehicle manufacturers

Provided medical-grade displays for patient monitoring equipment

Designed and manufactured ruggedized industrial displays for harsh environments

Supplied high-volume display solutions for consumer electronics brands

Start Your Project with JingTai LCD Today

Whether you need minor modifications to existing designs or complete custom display development, our team is ready to support your project with technical expertise and manufacturing excellence.

Contact Information:

Wendy - Foreign Trade Manager

Website: www.jingtailcddisplay.com

Email: wendy.wu@szjingtai.com.cn

Phone: +86 18520889665

WeChat: 18520889665

Let's discuss how we can bring your display vision to reality with our comprehensive OEM/ODM services.

JingTai LCD Technology Co., Ltd. – Advanced Display Solutions for Global Applications

Comprehensive LCD Module Manufacturer for Diverse Industries

JingTai LCD Technology Co., Ltd. specializes in the research, development, and manufacturing of high-quality liquid crystal display modules for global markets. With extensive experience and advanced manufacturing capabilities, we provide reliable display solutions that meet the stringent requirements of various electronic applications across multiple industries.

Wide Range of Applications

Our display modules are engineered to perform in diverse environments and applications, including:

1. Mobile Devices: Mobile phones, smartphones, and portable communication equipment

2. Wearable Technology: Smartwatches, fitness trackers, and medical wearables

3. Retail & Commercial: POS terminals, payment systems, and digital signage

4. Automotive Electronics: Center console displays, instrument clusters, and rear-seat entertainment systems

5. Portable Computing: Tablets, PDAs, and handheld computing devices

6. Security Systems: Access control panels, surveillance monitoring displays, and security equipment

7. Smart Home Devices: Home automation controls, smart appliance interfaces, and IoT displays

8. Home Appliances: Refrigerator displays, washing machine interfaces, and kitchen appliance screens

Advanced Product Capabilities

Size Range: Comprehensive selection from compact 0.96-inch to large 17-inch display modules, available in both standard and full-lamination configurations

High-Resolution Options:

WV (480×800) | FW (480×854) | FW+ (480×960)

QHD (540×960) | HD (720×1280) | HD+ (720×1440)

FHD (1080×1920) | FHD+ (1080×2160)

Cutting-Edge Technologies:

TN (Twisted Nematic) for cost-effective solutions

IPS (In-Plane Switching) for superior viewing angles and color reproduction

LTPS (Low-Temperature Polycrystalline Silicon) for high resolution and low power consumption

Advanced In-Cell technology for slimmer designs and enhanced optical performance

Innovative Design Capabilities:

Standard rectangular displays

Waterdrop notch designs for maximum screen-to-body ratio

"Beauty shoulder" curved displays for ergonomic integration

Blind-hole cutouts for innovative camera and sensor placement

Comprehensive Interface Support:

MCU interface for simple applications

SPI for serial communication

RGB interface for high-speed data transfer

LVDS for robust noise-resistant transmission

MIPI (4-lane/8-lane) for mobile applications

eDP for embedded display applications

Expert Research & Development Strength

Our 30-member R&D team consists of experienced display engineers, each with 10+ years of specialized LCM development experience. This expertise enables us to provide:

Rapid customized display solutions tailored to specific client requirements

Comprehensive technical support throughout the product lifecycle

Innovative solutions for challenging application environments

Continuous improvement and optimization of display performance

Quick problem-solving and troubleshooting capabilities

Quality Assurance & Global Standards

ISO 9001 certified manufacturing processes

RoHS and REACH compliant materials

Rigorous quality control at every production stage

Environmental testing capabilities

Reliability testing for extended product lifespan

Why Choose JingTai LCD?

Global Experience: Serving international markets with proven success

Technical Expertise: Deep understanding of display technologies and applications

Customization Capabilities: Flexible solutions for unique requirements

Quality Commitment: Consistent performance and reliability

Competitive Pricing: Cost-effective solutions without compromising quality

Contact Us for Your Display Needs

Whether you require standard modules or custom-designed solutions, our team is ready to provide expert guidance and competitive quotations.

Visit our website or contact our technical team to discuss your specific application requirements.
